中心距（mm） |
傳動比i |
輸入軸轉速（r/min） |
輸入軸轉速（r/min） |
|
500 |
600 |
750 |
1000 |
1500 |
500 |
600 |
750 |
1000 |
1500 |
|
額定輸入功率（kW） |
額定輸出功率（kW） |
|
100 |
10.0
12.5
16.0
20.0
25.0
31.5
40.0
50.0
63.0 |
7.34
5.76
4.94
4.05
3.29
2.74
2.12
1.77
1.44 |
8.17
6.53
5.58
4.60
3.75
3.10
2.42
2.02
1.69 |
9.25
7.53
6.42
5.32
4.34
3.58
2.82
2.33
1.99 |
10.64
8.90
7.56
6.30
5.16
4.22
3.37
2.77
2.31 |
11.73
10.30
8.71
7.33
6.03
4.87
3.98
3.22
2.60 |
1262
1225
1313
1268
1306
1271
1199
1203
1177 |
1171
1156
1250
1215
1252
1214
1157
1171
1172 |
1083
1091
1178
1124
1188
1176
1120
1114
1148 |
945
977
1052
1047
1071
1053
1016
1003
1013 |
695
754
807
822
835
810
800
780
762 |
|
125 |
10.0
12.5
16.0
20.0
25.0
31.5
40.0
50.0
63.0 |
12.55
9.86
8.46
6.93
8.64
4.70
3.64
3.05
2.47 |
13.97
11.17
9.55
7.86
6.41
5.32
4.16
3.46
2.91 |
15.81
12.89
10.99
9.09
7.43
6.13
4.84
4.00
3.41 |
18.20
15.23
12.94
10.77
8.82
7.23
5.77
4.74
3.96 |
20.09
17.65
14.89
12.55
10.30
8.34
6.81
5.52
4.47 |
2157
2096
2248
2196
2236
2178
2059
2068
2020 |
2001
1979
2141
2070
2143
2080
1985
2011
2012 |
1852
1868
2016
1922
2033
2016
1921
1911
1971 |
1617
1673
1800
1790
1831
1805
1742
1721
1740 |
1190
1292
1380
1406
1427
1389
1371
1335
1308 |
|
160 |
10.0
12.5
16.0
20.0
25.0
31.5
40.0
50.0
63.0 |
22.85
17.95
15.30
12.55
10.20
8.53
6.61
5.53
4.48 |
25.41
20.32
17.30
14.26
11.61
9.64
7.54
6.28
5.28 |
28.75
23.42
19.92
16.50
13.46
11.11
8.77
7.26
6.19 |
33.06
27.63
23.46
19.58
16.0
13.09
10.47
8.60
7.18 |
36.41
31.93
27.03
22.85
18.77
15.10
12.34
10.02
8.10 |
3928
3815
4068
3930
4043
3950
3737
3749
3664 |
3641
3598
3876
3766
3881
3771
3601
3646
3650 |
3368
3392
3652
3488
3686
3653
3484
3466
3575 |
2936
3035
3232
3253
3326
3269
3159
3122
3155 |
2156
2338
2506
2560
2599
2513
2483
2423
2371 |
|
200 |
10.0
12.5
16.0
20.0
25.0
31.5
40.0
50.0
63.0 |
39.07
30.70
26.32
21.52
17.54
14.59
11.32
9.50
7.67 |
43.47
34.76
29.74
24.44
19.95
16.50
12.93
10.77
9.04 |
49.20
40.10
34.23
28.28
23.12
19.02
15.04
12.45
10.60 |
56.60
47.34
40.31
33.52
27.47
22.43
17.97
14.74
12.31 |
62.42
54.77
46.41
39.07
32.13
25.91
21.22
17.14
13.87 |
6715
6524
6997
6742
6953
6757
6401
6439
6276 |
6227
6156
6665
6458
6669
6454
6173
6259
6252 |
3764
5808
6272
5977
6330
6256
5975
5945
6123 |
5027
5199
5605
5570
5706
5602
5422
5349
5405 |
3696
4010
4302
4377
4449
4313
4268
4146
4062 |
|
250 |
10.0
12.5
16.0
20.0
25.0
31.5
40.0
50.0
63.0 |
67.01
52.53
45.08
36.92
30.09
24.99
19.38
16.32
13.16 |
74.57
59.49
50.95
41.93
34.22
28.29
22.13
18.51
15.50 |
84.84
68.64
58.64
48.51
39.65
32.61
25.71
21.38
18.18 |
97.11
81.06
69.03
57.51
47.10
38.48
30.75
25.30
21.09 |
107.10
93.84
79.46
67.01
55.08
44.47
36.31
29.38
23.77 |
11776
11413
12262
12271
12213
11878
11253
11377
11083 |
10920
10772
11677
11746
11710
11345
10847
11046
11034 |
10103
10160
10991
10871
11107
10987
10490
10481
10791 |
8810
9096
9810
9776
10008
9839
9516
9421
9518 |
6478
7020
7528
7680
7803
7581
7490
7294
7149 |
|
315 |
10.0
12.5
16.0
20.0
25.0
31.5
40.0
50.0
63.0 |
117.30
99.96
83.90
65.10
53.45
44.94
33.86
28.46
23.63 |
130.45
108.20
91.88
73.23
59.74
49.50
38.66
32.29
27.04 |
148.10
120.00
102.80
84.76
69.22
57.04
44.98
37.33
31.72 |
169.58
141.78
120.54
100.55
82.24
67.25
53.73
44.20
36.82 |
187.20
164.22
138.72
117.30
96.19
77.62
63.44
51.41
41.51 |
20612
21718
22819
21653
21694
21360
19663
19839
19904 |
19102
19590
21059
20516
20444
19855
18954
19273
19250 |
17727
17763
19268
18996
19391
19217
18330
18298
18831 |
15385
15909
17130
17093
17474
17197
16626
16463
16615 |
11322
12285
13142
13443
13626
13232
13087
12765
12488 |
|
400 |
10.0
12.5
16.0
20.0
25.0
31.5
40.0
50.0
63.0 |
222.20
193.20
170.00
131.30
105.00
88.52
66.57
53.55
46.41 |
257.40
215.30
183.80
141.80
114.50
96.92
72.24
58.70
51.14 |
276.90
236.30
203.70
156.50
128.10
107.10
80.85
65.21
56.70 |
311.00
262.50
230.00
177.50
144.90
121.80
91.98
74.03
64.37 |
359.90
304.50
264.60
200.60
164.90
138.60
104.70
84.11
73.19 |
39045
41975
46237
44137
43118
42606
39161
37843
29650 |
37692
38981
42127
40174
39638
39360
35874
35504
36922 |
33143
34978
38180
35471
36293
36514
33355
32383
34114 |
28215
29456
32684
30512
31135
31511
28812
27926
29433 |
21768
22779
25067
23244
23622
23905
21864
21955
22311 |
|
500 |
10.0
12.5
16.0
20.0
25.0
31.5
40.0
50.0
63.0 |
393.90
329.70
286.70
218.40
180.60
152.30
114.50
92.82
80.85 |
424.40
361.20
306.60
24.050
198.50
164.90
126.00
101.40
88.31 |
462.50
395.90
340.20
263.60
219.50
183.80
138.60
112.40
97.34 |
511.50
432.60
382.20
293.00
243.60
206.90
154.40
123.90
108.20 |
582.50
486.20
431.60
326.60
278.30
233.10
176.40
141.80
122.90 |
69216
71631
77978
73417
74163
73305
67358
65595
69074 |
62146
65396
70273
68137
68718
66968
62571
61330
63758 |
55358
58603
63765
59746
62118
62664
57181
55818
58565 |
46406
48543
54312
50367
52344
53527
48364
46738
49475 |
35232
36372
40888
37844
39866
40203
36837
355660
37464 |
