JWB系列行星錐盤無級變速機的技術參數
JWB-X系列無級變速器的規格型號（即機座號）及其技術參數見表9.1-1。
|
機座號 |
01 |
02 |
03 |
04 |
05 |
06 | |||||||
|
電動機輸入功率/kW |
0.18 |
0.25 |
0.37 |
0.55 |
0.75 |
1.1 |
1.5 |
2.2 |
3 |
4 |
5.5 |
7.5 | |
|
電動機極數 |
4極（1500r/min） | ||||||||||||
|
變速器機型 |
輸出速度
/(r/min) |
許用輸出轉矩/(N·m) | |||||||||||
|
基本機型尺寸見
表9.1-2~表9.1-4 |
190~950 |
2.5~1.3 |
3.5~1.8 |
5.4~2.7 |
8~4 |
11~5.4 |
16~8 |
22~11 |
32~16 |
44~22 |
59~29 |
81~40 |
110~54 |
|
帶一對齒輪減速尺寸
見表9.1-5~表9.1-6 |
100~500 |
— |
6.5~3.4 |
10~4.9 |
15~7.4 |
21~10 |
30~15 |
41~20 |
58~30 |
82~40 |
109~54 |
150~74 |
205~101 |
|
80~400 |
— |
8~4 |
12.4~6.2 |
18.5~9 |
26~12.5 |
37~18.5 |
51~25 |
75~37 |
102~50.5 |
138~67 |
188~93 |
255~126 | |
|
60~300 |
— |
11~5.6 |
16.5~8.2 |
24.5~13 |
35~16.8 |
50~24.5 |
68~34 |
98~50 |
134~67.5 |
180~90 |
250~124 |
340~168 | |
|
40~200 |
— |
16~8.4 |
25~12 |
37~18.5 |
52~25 |
75~37 |
102~50.5 |
147~74 |
200~101 |
270~134 |
370~175 |
510~253 | |
|
帶二對齒輪減速尺寸
見表9.1-7~表9.1-8 |
30~150 |
— |
— |
— |
— |
— |
— |
— |
198~100 |
267~132 |
356~176 |
490~242 |
668~330 |
|
28~140 |
— |
— |
— |
52~26 |
73~35 |
105~52 |
143~71 |
— |
— |
— |
— |
— | |
|
25~125 |
— |
25~13 |
39~20 |
— |
— |
— |
— |
— |
— |
— |
— |
— | |
|
20~100 |
— |
— |
— |
— |
— |
— |
— |
294~145 |
401~198 |
535~264 |
735~363 |
1000~495 | |
|
18~90 |
— |
— |
— |
81~40 |
114~55 |
— |
— |
— |
— |
— |
— |
— | |
|
15~75 |
— |
42~22 |
65~32 |
— |
— |
196~97 |
268~132 |
— |
— |
— |
— |
— | |
|
13~65 |
— |
— |
— |
113~56 |
158~76 |
— |
— |
— |
— |
— |
— |
— | |
|
9~45 |
— |
70~37 |
105~54 |
— |
— |
— |
— |
— |
— |
— |
— |
— | |
|
8~40 |
— |
— |
— |
182~91 |
255~124 |
— |
— |
— |
— |
— |
— |
— | |
|
6.5~32.5 |
— |
— |
— |
225~112 |
316~151 |
— |
— |
— |
— |
— |
— |
— | |
|
帶三對齒輪減速尺寸
見表9.1-9~表9.1-10 |
4.7~23.5 |
— |
— |
204~102 |
292~146 |
426~207 |
613~303 |
837~413 |
— |
— |
— |
— |
— |
|
2~10 |
— |
— |
— |
426~343 |
— |
— |
— |
— |
— |
— |
— |
— | |
注：基本機型（當輸出轉速從高到低時）的傳動效率為81%~65%，滑差率為2%~6%，溫升為46~47℃。
JWB系列行星錐盤無級變速機的規格型號的外形及安裝尺寸
1）基本型的直出式底座聯接型（190D）外形及安裝尺寸見表9.1-2。
|
型號 |
機座號 |
安裝尺寸 |
輸出軸 |
輸入軸(Z) |
輸入孔(K) |
外形尺寸 |
凈重
/kg | |||||||||||||||||||||||
|
A1 |
A2 |
D3 |
D4 |
m |
d0 |
B1 |
d1 |
b1 |
c1 |
e1 |
d2 |
b2 |
c2 |
e2 |
d3 |
b3 |
c3 |
H |
H1 |
H2 |
L |
L1 |
L2 |
A |
B |
K |
R | |||
|
JWB-X**-190D |
01 |
25 |
5 |
— |
— |
— |
10 |
95 |
11f6 |
4 |
12.5 |
24 |
— |
— |
— |
— |
— |
— |
— |
188 |
70 |
145 |
356 |
— |
146 |
55 |
120 |
87 |
105 |
15 |
|
JWB-X**-190D |
02 |
55 |
7 |
— |
— |
— |
10 |
150 |
14f6 |
5 |
16 |
40 |
14f6 |
5 |
16 |
30 |
— |
— |
— |
210 |
80 |
168 |
410 |
293 |
200 |
90 |
190 |
121 |
105 |
22 |
|
JWB-X**B-190D |
02 |
55 |
7 |
110 |
130 |
M8 |
10 |
150 |
14f6 |
5 |
16 |
40 |
14f6 |
5 |
16 |
30 |
14F7 |
5 |
16.3 |
210 |
80 |
168 |
414 |
297 |
204 |
90 |
190 |
121 |
118 |
|
|
JWB-X**-190D |
03 |
66 |
7 |
— |
— |
— |
12 |
165 |
24f6 |
8 |
27 |
50 |
19f6 |
6 |
21.5 |
40 |
— |
— |
— |
255 |
105 |
212 |
490 |
356 |
246 |
125 |
212 |
147 |
110 |
38 |
|
JWB-X**B-190D |
03 |
66 |
7 |
130 |
165 |
M10 |
12 |
165 |
24f6 |
8 |
27 |
50 |
19f6 |
6 |
21.5 |
40 |
19F7 |
6 |
21.8 |
268 |
105 |
212 |
493 |
359 |
249 |
125 |
212 |
147 |
120 |
|
|
JWB-X**B-190D |
04 |
75 |
18 |
— |
— |
— |
14.5 |
185 |
28f6 |
8 |
31 |
60 |
24f6 |
8 |
28 |
43 |
— |
— |
— |
307 |
125 |
252 |
602 |
435 |
320 |
145 |
235 |
187 |
147 |
61 |
|
JWB-X**B-190D |
05 |
85 |
15 |
— |
— |
— |
18.5 |
240 |
38f6 |
10 |
41 |
80 |
28f6 |
8 |
32 |
60 |
— |
— |
— |
368 |
150 |
313 |
747 |
618 |
465 |
148 |
310 |
297 |
160 |
134 |
|
JWB-X**B-190D |
06 |
120 |
12 |
— |
— |
— |
21 |
295 |
42f6 |
12 |
45 |
80 |
38f6 |
10 |
43 |
70 |
— |
— |
— |
452 |
190 |
397 |
980 |
735 |
550 |
185 |
380 |
367 |
196 |
198 |
基本型的直出式法蘭聯接型（190F）外形及安裝尺寸
|
型號 |
機座
號 |
安裝尺寸 |
輸出軸 |
輸入軸(Z) |
輸入孔(K) |
外形尺寸 |
凈重
/kg | ||||||||||||||||||||||
|
D1 |
D2 |
D3 |
D4 |
m |
d0 |
J |
F |
d1 |
b1 |
c1 |
e1 |
d2 |
b2 |
c2 |
e2 |
d3 |
b3 |
c3 |
H |
H2 |
L |
L1 |
L2 |
B |
K |
R | |||
|
JWB-X**-190F |
01 |
115 |
95 |
— |
— |
— |
10 |
24 |
3 |
11f6 |
4 |
12.5 |
24 |
— |
— |
— |
— |
— |
— |
— |
189 |
146 |
351 |
— |
140 |
55 |
81 |
105 |
15 |
|
JWB-X**-190F |
02 |
130 |
110 |
— |
— |
— |
10 |
40 |
3.5 |
14f6 |
5 |
16 |
40 |
14f6 |
5 |
16 |
30 |
— |
— |
— |
210 |
168 |
375 |
258 |
165 |
90 |
86 |
105 |
22 |
|
JWB-X**B-190F |
02 |
130 |
110 |
110 |
130 |
M8 |
9 |
30 |
3.5 |
14f6 |
5 |
16 |
30 |
14f6 |
5 |
16 |
30 |
14F7 |
5 |
16.3 |
210 |
168 |
364 |
247 |
154 |
90 |
81 |
118 |
|
|
JWB-X**-190F |
03 |
165 |
130 |
— |
— |
— |
12 |
50 |
3.5 |
24f6 |
8 |
27 |
50 |
19f6 |
6 |
21.5 |
40 |
— |
— |
— |
250 |
207 |
453 |
318 |
208 |
125 |
109 |
110 |
38 |
|
JWB-X**B-190F |
03 |
165 |
130 |
130 |
165 |
M10 |
11 |
40 |
3.5 |
19f6 |
6 |
21.5 |
40 |
19f6 |
6 |
21.5 |
40 |
19F7 |
6 |
21.8 |
262 |
207 |
424 |
289 |
179 |
125 |
88 |
120 |
|
|
JWB-X** -190F |
04 |
215 |
180 |
— |
— |
— |
14.5 |
60 |
4 |
28f6 |
8 |
31 |
60 |
24f6 |
8 |
28 |
43 |
— |
— |
— |
307 |
252 |
593 |
422 |
307 |
145 |
174 |
147 |
61 |
|
JWB-X** -190F |
05 |
265 |
230 |
— |
— |
— |
16.5 |
80 |
4 |
38f6 |
10 |
41 |
80 |
28f6 |
8 |
32 |
60 |
— |
— |
— |
368 |
313 |
753 |
562 |
412 |
148 |
244 |
160 |
134 |
|
JWB-X** -190F |
06 |
300 |
250 |
— |
— |
— |
21 |
80 |
5 |
42f6 |
12 |
45 |
80 |
38f6 |
10 |
43 |
70 |
— |
— |
— |
437 |
382 |
787 |
608 |
423 |
350 |
239 |
196 |
198 |
基本型的直出式底座聯接型（190DA）外形及安裝尺寸
|
型號 |
機座
號 |
安裝尺寸 |
輸出軸 |
輸入軸(Z) |
外形尺寸 |
凈重
/kg | ||||||||||||||||||
|
A1 |
A2 |
d0 |
B1 |
d1 |
b1 |
c1 |
e1 |
d2 |
b2 |
c2 |
e2 |
H |
H1 |
H2 |
L |
L1 |
L2 |
A |
B |
K |
R | |||
|
JWB-X**A-190D |
03 |
125 |
30 |
12 |
160 |
20f6 |
6 |
22.5 |
40 |
19f6 |
6 |
21.5 |
30 |
256 |
106 |
213 |
422 |
251 |
182 |
150 |
190 |
93 |
110 |
38 |
|
JWB-X**A-190D |
04 |
140 |
50 |
12 |
180 |
25f6 |
8 |
28 |
50 |
24f6 |
8 |
27 |
40 |
307 |
125 |
252 |
489 |
314 |
229 |
165 |
230 |
106 |
147 |
60 |
一對齒輪減速底座聯接型（40~100D）外形及安裝尺寸
|
型號 |
機座號 |
安裝尺寸 |
輸出軸 |
輸入軸(Z) |
輸入孔(K) |
外形尺寸 |
凈重
/kg | |||||||||||||||||||||||
|
A1 |
A2 |
D3 |
D4 |
m |
d0 |
B1 |
d1 |
b1 |
c1 |
e1 |
d2 |
b2 |
c2 |
e2 |
d3 |
b3 |
c3 |
H |
H1 |
H2 |
L |
L1 |
L2 |
A |
B |
K |
R | |||
|
JWB-X**-***D |
02 |
64 |
2 |
— |
— |
— |
12 |
148 |
24f6 |
8 |
27 |
50 |
14f6 |
5 |
16 |
30 |
— |
— |
— |
210 |
131 |
168 |
435 |
318 |
225 |
112 |
190 |
136 |
105 |
25 |
|
JWB-X**B-***D |
02 |
64 |
2 |
110 |
130 |
M8 |
12 |
148 |
24f6 |
8 |
27 |
50 |
14f6 |
5 |
16 |
30 |
14F7 |
5 |
16.3 |
210 |
131 |
168 |
439 |
322 |
229 |
112 |
190 |
136 |
118 |
|
|
JWB-X** -***D |
03 |
70 |
7 |
— |
— |
— |
14.5 |
165 |
28f6 |
8 |
31 |
60 |
19f6 |
6 |
21.5 |
40 |
— |
— |
— |
250 |
162 |
208 |
530 |
390 |
280 |
130 |
212 |
171 |
110 |
43 |
|
JWB-X**B-***D |
03 |
70 |
7 |
130 |
165 |
M10 |
14.5 |
165 |
28f6 |
8 |
31 |
60 |
19f6 |
6 |
21.5 |
40 |
19F7 |
6 |
21.8 |
262 |
162 |
208 |
533 |
393 |
283 |
130 |
212 |
171 |
120 |
|
|
JWB-X**-***D |
04 |
85 |
0 |
— |
— |
— |
14.5 |
196 |
38f6 |
10 |
41 |
70 |
24f6 |
8 |
28 |
43 |
— |
— |
— |
299 |
195 |
244 |
604 |
435 |
320 |
155 |
240 |
177 |
147 |
70 |
|
JWB-X**-***D |
05 |
130 |
14 |
— |
— |
— |
18.5 |
240 |
48f6 |
14 |
51.5 |
100 |
28f6 |
8 |
32 |
60 |
— |
— |
— |
367 |
252 |
312 |
888 |
705 |
552 |
196 |
310 |
364 |
160 |
150 |
|
JWB-X**-***D |
06 |
150 |
22 |
— |
— |
— |
21 |
280 |
55f6 |
16 |
59 |
110 |
38f6 |
10 |
43 |
70 |
— |
— |
— |
444 |
300 |
389 |
1090 |
845 |
660 |
230 |
350 |
446 |
196 |
250 |
一對齒輪減速法蘭聯接型（40~100F）外形及安裝尺寸
|
型號 |
機座
號 |
安裝尺寸 |
輸出軸 |
輸入軸(Z) |
輸入孔(K) |
外形尺寸 |
凈重
/kg | |||||||||||||||||||||||
|
D1 |
D2 |
D3 |
D4 |
m |
d0 |
J |
F |
d1 |
b1 |
c1 |
e1 |
d2 |
b2 |
c2 |
e2 |
d3 |
b3 |
c3 |
H |
H1 |
H2 |
L |
L1 |
L2 |
B |
K |
R | |||
|
JWB-X**-***F |
02 |
130 |
110 |
— |
— |
— |
12 |
50 |
4 |
24f6 |
8 |
27 |
50 |
14f6 |
5 |
16 |
31 |
— |
— |
— |
184 |
105 |
142 |
450 |
333 |
240 |
150 |
151 |
105 |
25 |
|
JWB-X**B-***F |
02 |
130 |
110 |
110 |
130 |
M8 |
12 |
50 |
4 |
24f6 |
8 |
27 |
50 |
14f6 |
5 |
16 |
31 |
14F7 |
5 |
16.3 |
184 |
105 |
142 |
454 |
337 |
244 |
150 |
151 |
118 |
|
|
JWB-X**-***F |
03 |
165 |
130 |
— |
— |
— |
12 |
60 |
4.5 |
28f6 |
8 |
31 |
60 |
19f6 |
6 |
21.5 |
40 |
— |
— |
— |
198 |
110 |
156 |
530 |
390 |
280 |
200 |
171 |
110 |
43 |
|
JWB-X**B-***F |
03 |
165 |
130 |
130 |
165 |
M10 |
12 |
60 |
4.5 |
28f6 |
8 |
31 |
60 |
19f6 |
6 |
21.5 |
40 |
19F7 |
6 |
21.8 |
211 |
110 |
156 |
533 |
393 |
283 |
200 |
171 |
120 |
|
|
JWB-X** -***F |
04 |
215 |
180 |
— |
— |
— |
14.5 |
70 |
4.5 |
38f6 |
10 |
41 |
70 |
24f6 |
8 |
28 |
43 |
— |
— |
— |
251 |
147 |
196 |
625 |
455 |
340 |
250 |
197 |
147 |
70 |
|
JWB-X** -***F |
05 |
265 |
230 |
— |
— |
— |
14.5 |
100 |
5 |
48f6 |
14 |
51.5 |
100 |
28f6 |
8 |
32 |
60 |
— |
— |
— |
275 |
160 |
220 |
888 |
705 |
552 |
300 |
364 |
160 |
150 |
|
JWB-X** -***F |
06 |
300 |
250 |
— |
— |
— |
21 |
110 |
5 |
55f6 |
16 |
59 |
110 |
38f6 |
10 |
43 |
70 |
— |
— |
— |
342 |
196 |
287 |
1090 |
845 |
660 |
350 |
440 |
196 |
196 |
二對齒輪減速底座聯接型（6.5~30D）外形及安裝尺寸
|
型號 |
機座
號 |
安裝尺寸 |
輸出軸 |
輸入軸(Z) |
輸入孔(K) |
外形尺寸 |
凈重
/kg | |||||||||||||||||||||||
|
D1 |
D2 |
D3 |
D4 |
m |
d0 |
J |
F |
d1 |
b1 |
c1 |
e1 |
d2 |
b2 |
c2 |
e2 |
d3 |
b3 |
c3 |
H |
H1 |
H2 |
L |
L1 |
L2 |
D |
K |
R | |||
|
JWB-X**-**F |
02 |
130 |
110 |
— |
— |
— |
12 |
55 |
4 |
28f6 |
8 |
31 |
55 |
14f6 |
5 |
16 |
31 |
— |
— |
— |
238 |
108 |
196 |
505 |
388 |
295 |
150 |
201 |
105 |
29 |
|
JWB-X**B-**F |
02 |
130 |
110 |
110 |
130 |
M8 |
12 |
55 |
4 |
28f6 |
8 |
31 |
55 |
14f6 |
5 |
16 |
31 |
14F7 |
5 |
16.3 |
238 |
108 |
196 |
509 |
392 |
299 |
150 |
201 |
118 |
|
|
JWB-X0.25-25FS |
02 |
110 |
86 |
— |
— |
— |
10 |
38.5 |
4 |
20f6 |
6 |
22.5 |
38.5 |
— |
— |
— |
— |
— |
— |
— |
210 |
80 |
168 |
446 |
— |
236 |
136 |
158 |
108 |
25 |
|
JWB-X**-**F |
03 |
130 |
110 |
— |
— |
— |
10 |
60 |
4 |
28f6 |
8 |
31 |
60 |
19f6 |
6 |
21.5 |
40 |
— |
— |
— |
277 |
127 |
234 |
595 |
460 |
350 |
160 |
241 |
110 |
49 |
|
JWB-X**B-**F |
03 |
130 |
110 |
130 |
165 |
M10 |
10 |
60 |
4 |
28f6 |
8 |
31 |
60 |
19f6 |
6 |
21.5 |
40 |
19F7 |
6 |
21.8 |
290 |
127 |
234 |
598 |
463 |
353 |
160 |
241 |
120 |
|
|
JWB-X0.75-6.5F |
03 |
130 |
110 |
— |
— |
— |
10 |
60 |
4 |
30f6 |
8 |
33 |
60 |
19f6 |
6 |
21.5 |
40 |
— |
— |
— |
277 |
127 |
234 |
595 |
460 |
350 |
160 |
241 |
110 |
49 |
|
JWB-X**-**F |
04 |
215 |
180 |
— |
— |
— |
14.5 |
70 |
4.5 |
38f6 |
10 |
41 |
70 |
24f6 |
8 |
28 |
43 |
— |
— |
— |
350 |
168 |
295 |
690 |
520 |
405 |
250 |
262 |
147 |
77 |
|
JWB-X1.5-21F |
04 |
165 |
130 |
— |
— |
— |
12 |
60 |
3.5 |
30f6 |
8 |
33 |
60 |
— |
— |
— |
— |
— |
— |
— |
302 |
130 |
247 |
640 |
— |
355 |
200 |
222 |
147 |
70 |
|
JWB-X**-**F |
05 |
265 |
230 |
— |
— |
— |
14.5 |
110 |
5 |
55f6 |
16 |
59 |
110 |
28f6 |
8 |
32 |
60 |
— |
— |
— |
448 |
230 |
393 |
980 |
798 |
645 |
300 |
447 |
160 |
174 |
|
JWB-X**-**F |
06 |
300 |
250 |
— |
— |
— |
18.5 |
140 |
5 |
70f6 |
20 |
74.5 |
140 |
38f6 |
10 |
43 |
70 |
— |
— |
— |
526 |
264 |
471 |
1260 |
1005 |
820 |
350 |
576 |
196 |
270 |
二對齒輪減速法蘭聯接型（6.5~30F）外形及安裝尺寸
|
型號 |
機座
號 |
安裝尺寸 |
輸出軸 |
輸入軸(Z) |
輸入孔(K) |
外形尺寸 |
凈重
/kg | |||||||||||||||||||||||
|
A1 |
A2 |
D3 |
D4 |
m |
d0 |
B1 |
d1 |
b1 |
c1 |
e1 |
d2 |
b2 |
c2 |
e2 |
d3 |
b3 |
c3 |
H |
H1 |
H2 |
L |
L1 |
L2 |
A |
B |
K |
R | |||
|
JWB-X**-**D |
02 |
85 |
18 |
— |
— |
— |
12 |
150 |
28f6 |
8 |
31 |
55 |
14f6 |
5 |
16 |
31 |
— |
— |
— |
240 |
110 |
198 |
505 |
388 |
295 |
146 |
190 |
201 |
105 |
29 |
|
JWB-X**B-**D |
02 |
85 |
18 |
110 |
130 |
M8 |
12 |
150 |
28f6 |
8 |
31 |
55 |
14f6 |
5 |
16 |
31 |
14F7 |
5 |
16.3 |
240 |
110 |
198 |
509 |
392 |
299 |
146 |
190 |
201 |
118 |
|
|
JWB-X0.25-25DS |
02 |
76 |
13 |
— |
— |
— |
10 |
105 |
20f6 |
6 |
22.5 |
38.5 |
— |
— |
— |
— |
— |
— |
— |
210 |
80 |
168 |
446 |
— |
236 |
121 |
128 |
158 |
105 |
25 |
|
JWB-X**-**D |
03 |
106 |
26 |
— |
— |
— |
14.5 |
174 |
28f6 |
8 |
31 |
60 |
19f6 |
6 |
21.5 |
40 |
— |
— |
— |
302 |
152 |
259 |
585 |
450 |
340 |
168 |
212 |
231 |
110 |
49 |
|
JWB-X**B-**D |
03 |
106 |
26 |
130 |
165 |
M10 |
14.5 |
174 |
28f6 |
8 |
31 |
60 |
19f6 |
6 |
21.5 |
40 |
19F7 |
6 |
21.8 |
315 |
152 |
259 |
588 |
453 |
343 |
168 |
212 |
231 |
120 |
|
|
JWB-X0.75-6.5D |
03 |
106 |
26 |
— |
— |
— |
14.5 |
174 |
30f6 |
8 |
31 |
60 |
19f6 |
6 |
21.5 |
40 |
— |
— |
— |
302 |
152 |
259 |
585 |
450 |
340 |
168 |
212 |
231 |
110 |
49 |
|
JWB-X**-**D |
04 |
130 |
27 |
— |
— |
— |
14.5 |
200 |
38f6 |
10 |
41 |
70 |
24f6 |
8 |
28 |
43 |
— |
— |
— |
354 |
172 |
299 |
690 |
520 |
405 |
185 |
255 |
262 |
147 |
77 |
|
JWB-X**-**D |
05 |
180 |
36 |
— |
— |
— |
18.5 |
246 |
55f6 |
16 |
59 |
100 |
28f6 |
8 |
32 |
60 |
— |
— |
— |
453 |
235 |
398 |
980 |
798 |
645 |
264 |
320 |
447 |
160 |
174 |
|
JWB-X**-**D |
06 |
250 |
55 |
— |
— |
— |
21 |
300 |
70f6 |
20 |
74.5 |
110 |
38f6 |
10 |
43 |
70 |
— |
— |
— |
542 |
280 |
487 |
1260 |
1005 |
820 |
345 |
384 |
576 |
196 |
270 |
| 頁次：1/2 每頁10條 共12條信息 分頁：[1][2] |
