緊配合軸徑與孔公差之推薦
|
軸尺寸 |
軸公差 |
孔尺寸 |
孔公差 |
干涉量 |
軸尺寸 |
軸公差 |
孔尺寸 |
孔公差 |
干涉量 |
|
14 |
+0.018
+0.007 |
14 |
-0.004
-0.015 |
0.011
0.033 |
56 |
+0.030
+0.011 |
56 |
-0.005
-0.024 |
0.016
0.054 |
|
15 |
15 |
60 |
60 |
|
16 |
16 |
64 |
64 |
|
17 |
17 |
65 |
65 |
|
18 |
18 |
70 |
70 |
|
19 |
+0.021
+0.008 |
19 |
-0.004
-0.017 |
0.012
0.038 |
75 |
75 |
|
20 |
20 |
80 |
80 |
|
22 |
22 |
85 |
+0.035
+0.013 |
85 |
-0.006
-0.028 |
0.019
0.063 |
|
24 |
24 |
90 |
90 |
|
25 |
25 |
95 |
95 |
|
26 |
26 |
100 |
100 |
|
28 |
28 |
105 |
105 |
|
30 |
30 |
110 |
110 |
|
32 |
+0.029
+0.009 |
32 |
-0.004
-0.020 |
0.013
0.045 |
115 |
115 |
|
34 |
34 |
120 |
120 |
|
35 |
35 |
125 |
+0.040
+0.015 |
125 |
-0.008
-0.033 |
0.023
0.073 |
|
36 |
36 |
130 |
130 |
|
38 |
38 |
140 |
140 |
|
40 |
40 |
150 |
150 |
|
42 |
42 |
160 |
160 |
|
44 |
44 |
170 |
170 |
|
45 |
45 |
180 |
180 |
|
46 |
46 |
200 |
+0.046
+0.017 |
200 |
-0.008
-0.037 |
0.023
0.083 |
|
48 |
48 |
225 |
225 |
|
50 |
50 |
250 |
250 |
|
52 |
+0.030
+0.011 |
52 |
-0.005
-0.024 |
0.016
0.054 |
|
|
|
|
|
|
55 |
55 |
|
|
|
|
|
